Troubleshooting
6-22
4
Open the bottom cover of the duplex unit (B2) and
remove the jammed paper.
If the paper tears, remove every loose scraps from the
copier inside.
5
Close the cover B2.
6
Open the cover B3 and remove the jammed paper
from there.
If the paper tears, remove every loose scraps from the
copier inside.
7
Close the cover B3.
8
Replace the duplex unit in its original position and push it back in securely.
9
Close the front cover.
Document Processor
Follow the steps as below to clear paper
jams in the document processor.
1
Open the document processor top cover.
B
2
Paper misfeed.
3.Hold up Doc ument Proc es s or T ray
4.Remove the original
5.Close Document Processor Top Cover
2.T urn left-side dial
1.Open Document Proces sor T op Cover
