Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
[Set of 2 pcs. dust filter (No1)]
[Set of 2 pcs. filter mounting holders + 6 pcs. double sided tape (No2]]
[Set of 6 pcs. double sided tape (No3)]
[LSU drive unit (No4, 5)]
(Extract from FIG.13 of P7240cdnparts list)
*Ref No.500s are not for supply to field
*1: Wire only, listed in Wire Section in other than FIG.13
Ref No.10：
PARTS PWB ASSY DRUM
CONNECT SP
(for 40ppm printer: 302NT9402_
for the other:302NR9412_)
Ref No.9：
PARTS DC MOTOR ASSY SP
（302NG9443_）
*1：
CONN.CORD ASSY S03959
ENGINE-LSU CL
（302NR4629_）
