―11―
Note:
¡
Somecircuitshaveanunstableinsulationresistance,whichcauses
thereadingtovaryduringmeasurement.
¡
The instrument may generate a high pitch tone during
measurement.Thisisnotafailure.
¡
Ifthecircuit under testhasalarge capacitive load,itmay take
sometimebeforethefinalreadingcanbeobtained.
¡
Oninsulationresistancerange,DC voltage is suppliedthrough
earthandLineprobes,withearthprobehavingpositivepolarity.
Earthprobeshouldbeconnectedtotheearthconductorinthecircuit
undertest.Suchconnectionisknowntobemoresuitable for
insulationtests sincean insulationresistance value measured with
thepositive side connectedtoearth istypicallyless than thattaken
throughthereversedconnection.
DANGER
¡
WhentheTestbuttonorRemotecontrolswitchispressedwiththe
Rangeselectorswitchsettoaninsulationresistancerange
position,takecarenot to touch thetipofthetest probe orthe
circuitundertestwhereahighvoltageispresentinordertoavoid
possibleshockhazard.
¡
DonotmakemeasurementwiththeBatterycoverremoved.
CAUTION
¡
Ensurethat thecircuitundertestisde-energizedprior toany
insulationtesting.
(1)Checkthe maximumvoltagethat maybeapplied to thecircuit
undertest.SettheRange selector switch toadesiredinsulation
resistancerange.KeeptheSafetykeypresseddownwhenturning
theRangeselectorswitchto500Vand1000Vposition.(Onlythe
500VrangeisavailableonKEW3022.)Themessage"no"is
displayedonthe LCD whenturningtheRange selector switch
withoutpressingtheSafetykey.
¡
BuzzersoundswhentheSafetykeyispresseddown.
KeeptheSafetykeypresseddownwhenswitching500Vand1000V.
Fig.5
