USER’S MANUAL OF LK-320E
LABEL & MARK INDUSTRIES COMPANY
15
Installation of Ribbon
[Attention]
The Ribbon can not be detected by the printer if it is not properly installed.
Therefore see that the Ribbon is placed into the correct place. If the Ribbon
becomes loose, the machine may be unable to detect the Ribbon and the ribbon is
prone to be torn broken or corrugated. So be sure to roll tight the ribbon prior to
installation.
4． Close the protective cover
Removal of Ribbon
1． Open the protective cover
★ Make sure the print head is not pressed on the print rubber roll, in other words
make sure the print head is released;
[Attention]
If the print head is found pressed upon the rubber roll, please close the protective
cover and switch off the power and then switch on the printer about 3 seconds later.
In this way, the printer will initialize anew and the print head will return to a proper
place.
2． Raise the Ribbon and take it off carefully.
To Next Page
