USER’S MANUAL OF LK-320E
LABEL & MARK INDUSTRIES COMPANY
40
Set ( -2.0):
Then sent -2.0~+2.0 can to adjust the position of printer head.
For example:
Now the printer head position is -1.0. If input “0.2” the printer head position will
move upwards 0.2mm. The position is -0.8mm.
Cutter position Adjustment
Choose Cutter and the screen will display as follows:
Range(+0.0):
Then sent -100.0~+100.0 can to adjust the position of cutter. The unitage
1=0.0847mm.
For example:
If input -10 the cutter line position will move 0.847mm to left.
4.2.9.8 File
Use this function you can save all the input contents as a files in the machine’s
internal memory. To save it as a file, you need to give it a mane. You can open
or delete saved files.
Press [Enter], then the screen will display as follows:
Save File
Press [↑] or [↑] to choose Save File , Open File or Delete File , and
press [Enter].
Save file
