USER’S MANUAL OF LK-320E
LABEL & MARK INDUSTRIES COMPANY
37
4.2.9.6 Cut depth
The initial setting value for half-cut depth is “0”.
¾ If you have selectd the tube after press [half-cut depth] and the screen
will display as follows:
Tube cut depth
Press[↑] or [↓] to select Tube cut depth or Full-cut depth and press
[Enter].
Adjust half-cut depth of tube
Select Tube Cut depth and press [Enter], then the screen will display as
follows:
half-cut depth:
Then
-3 -2 -1 0 1 2 3
Use [→] or [← ]to make your selection and press [Enter] to finish sleeve tube
semi-cutting depth. Cutting depth ascends from -3 to +3.
If you have chosen a semi-depth of +3 but are not satisfactory with the
semi-cutting results, then you may need to replace your cutter assembly.
Adjust full-cut depth
Select Full-cut depth and press [Enter] to finish your full cutting depth
setting. The cutting depth ascends from -3 to +3.
