Operation
General Characteristics
Monitor Case  High impact polycarbonate.
 Mounting locations reinforced for crash safety.
 Mounting points to accommodate either in-dash or
pedestal base mounting configurations.
External Connectors  Located on rear of monitor above VESA mounting
location.
 Maximum protrusion from case: 7mm (~0.27")
 Connectors are labeled for easy identification.
 Five (5) connectors provided: Video (BNC), VGA
(DB-15), Touch Screen (DB-9), Power (4-pin
Molex), and Audio (3.5mm)
Operator Controls  On/Off Switch located on bottom left of monitor
 Backlight luminance control on bottom left of
display. Two push-button switches: one for increase
and one for decrease of luminance.
 OSD (On-Screen Display) function control on rear of
display. Four switches to control: Menu, Input, Menu
Up, and Menu Down.
 Video/VGA selection switch controlled by lower
OSD switch (Menu Down) when OSD is not enabled.
 Volume Control on bottom right of display. Two
push-button switches: one for increase and one for
decrease of volume.
 Controls are labeled for easy identification.
 Maximum protrusion: 3mm (~0.12")
Maximum Dimensions  Maximum Height: 238mm (~9.5")
 Maximum Width: 306mm (~12.0")
 Maximum Depth: 49mm (~2.0")
Weight Maximum Overall Weight: 2.6 kg (~5.7 lbs)
LCD
Resolution  Auto-scaling of standard PC resolutions (640x480,
800x600, 1024x768, 1280x1024) to native LCD
resolution.
 XGA 1024x768
Color Depth 24-bit color (16.7M colors)
Aspect Ratio 4x3, using pixels with a 1:1 aspect ratio
Contrast Ratio Minimum On Axis 400:1
Grayscale Inversion Minimum viewing cone: +/-60ºH , 0º to +60ºV
