L3 Mobile-Vision MobileVu User Manual

Front Panel Control
MobileVu Display User Guide  7.12.2011
L3 Communications Mobile-Vision  Proprietary
Page 3
Front Panel Control
Rear Panel Control
Volume control
Brightness control
On/Off switch; to
power on or off,
button must be
depressed for
four seconds
Power Input
Video BNC connector
VGA connector;
standard DB-
15 pin
connector
Touch Screen
connector; standard
DB-9 serial connector
3.5 mm audio jack
Menu buttons;
Select Up, Select
Down, Input Select

L3 Mobile-Vision MobileVu Specifications

General

Brand	L3 Mobile-Vision
Model	MobileVu
Category	Monitor
Language	English
