COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
Model FA5000
Initial Issue Page 308
Sep. 30/11
Disassembly
23–70–40
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
C. Rear Cover Removal
(See Figure 305 or IPL Figure 1, Item 10)
REAR COVER REMOVAL PROCEDURE
(1) Remove the two screws (1−15) used to secure the bottom of rear cover (1−10)
to the rear part of the chassis mounting (1−100)
(2) Loosen the four captive screws (1−20) used to secure the four corners of rear
cover (1−10) to the rear part of the Shielded Housing (1−5). Remove the two
screws (1−20) used to secure the middle of rear cover (1−10) to the rear part of
the Shielded Housing (1−5)
(3) Slide rear cover (1−10) straight back from recorder until the AI (1−30) and MP
(1−50) PWAs separate at each other’s connector. For P/N: 5001−6133−11
only, remove Video cable connector from the AI (1−30).
(4) Remove the rear cover (1−10) and remove the four washers (1−25) on the cap-
tive screws from inside corner of the rear cover.
