COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
Model FA5000
Mar. 16/16
Table of Contents
23–70–40
Rev. 06 Page xxxiii
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
LIST OF TABLES
TABLE TITLE Page
Table 1. Shop Verification 6...........................................................
Table 1. Cockpit Area Microphone Pre-Amplifier Input Attenuation Decode 7................
Table 2. Processor Board PWA to Aircraft Interface PWA, P1 7...........................
Table 3. Hold Up Capacitor Voltage to CPU PWA, J6 15.................................
Table 4. Hold Up Capacitor Voltage Return to CPU PWA, J7 15..........................
Table 5. Aircraft Interface PWA to Video Board PWA, J4 15..............................
Table 6. P/N: 5001−61XX−11 Pin Outs and Signal Descriptions 17.......................
Table 101. 17TES0700 READOUT CENTER/7 (ROC/7) 104............................
Table 102. Underwater Locator Beacon Test Using L−3AR Test Set P/N: 17TES0015 129....
Table 201. Recommended Test Equipment 201........................................
Table 202. FA5000CVDR Status Entry: Checksum Value 209............................
Table 203. Underwater Locator Beacon Test Using L−3AR Test Set P/N: 17TES0015 215...
Table 204. Aircraft Interface Troubleshooting Chart 216.................................
Table 205. Main Processor Troubleshooting Chart 223..................................
Table 206. CSMU Troubleshooting Chart 234..........................................
Table 401. Cleaning Materials Required 401...........................................
Table 701. Required Assembly Materials 701..........................................
Table 801. Model FA5000 Environmental Characteristics 804............................
Table 901. 17TES0700 READOUT CENTER/7 (ROC/7) 902............................
