COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
Model FA5000
Initial Issue Page 1005
Sep. 30/11
Illustrated Parts List
23–70–40
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
10. CONFIGURATION MATRIX
Listed below are the current configurations for the FA5001 Cockpit Voice Data Recorder
(CVDR). Part Number 5001-610311 is capable of storing 2 hours of voice and flight data
and has Internal RIPS, OMS and datalink capabilities. P/N: 5001613311 has video re-
cording capability.
5001610311 CVDR, TRAYLESS, INTERNAL RIPS, Data link, OMS
5001613311 CVDR, TRAYLESS, INTERNAL RIPS, Data link, OMS, Video
5003610311 CVDR, TRAYLESS, INTERNAL RIPS, Data link, OMS, 2GB Memory
NUMERICAL INDEX
PART NUMBER AIRLINE
PART NO.
FIG.
ITEM
TTL
REQ
BB1P041H05 1 55 2
MS1699554 1 150 4
MS5195712 1 135/180/165 12
MS5195726 1 35 6
MS5195728 1 170 1
MS5195744 1 20 6
MS24693C1 1 115 2
MS24693C273 1 15 2
MS24693C3 1 40 4
MS24693C48 1 125 6
MS3533373 1 130 6
MW0242006S 1 75 2
010E527800 1 110 1
016E527800 1 145 2
0249800443 1 190 1
024E516200 1 85 1
042E527800 1 100 1
MRJ25831B 1 80 1
075E516102 1 10 1
075E535200 1 60 1
11104AL9 1 70 1
136E516102 1 5 1
189E516100 1 140 1
2056T440SS20 1 185 3
205E504407 1 50 1
