L3 FA5000 Component Maintenance Manual With Illustrated Parts List

COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
Model FA5000
Initial Issue Page 1009
Sep. 30/11
Illustrated Parts List
23–70–40
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
FIG.
ITEM
PART
NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1234567
EFF
CODE
UNITS
PER
ASSY
1
1A 5001−6103−11 COCKPIT VOICE DATA RECORDER
FA5001 CVDR, DATALINK
28 VDC ONLY
ARF
1B 5001−6133−11 COCKPIT VOICE DATA RECORDER
FA5001 CVDR, DATALINK, VIDEO
WITH VIDEO, 28 VDC ONLY
BRF
1C 5001−6103−10 Deleted C RF
1D 5003−6103−11 COCKPIT VOICE DATA RECORDER
FA5001 CVDR, DATALINK
28 VDC ONLY 2 GB MEMORY
DRF
1E 5011−6103−11 COCKPIT VOICE DATA RECORDER
FA5001 CVDR, DATALINK
28 VDC, 90-DAY BEACON
ERF
5 136E5161-02 .HOUSING PEEK SHIELDED
1
ATTACHING PARTS
10 075E5161-10 .COVER,REAR HOUSING SHLD 1
15 MS24693-C273 .SCR, FLH, 10-32 X3/4
(V06141) (2290200465)
2
20 MS51957-44 .SCR,PNH ,6-32 X1/4
(V06141) (2290200101)
6
25 2739800199 .Deleted
***
30 205E5452-02 .PWA,AI,FA5001 38999 1
ATTACHING PARTS
35 MS51957-26 .SCR,PNH ,6-32 X1/4
(V06141) (2290200083)
6
Rev. 06 Page 1009
Mar. 16/16
