COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
Model FA5000
Initial Issue Page 1011
Sep. 30/11
Illustrated Parts List
23–70–40
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
FIG.
ITEM
PART
NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1234567
EFF
CODE
UNITS
PER
ASSY
1
ATTACHING PARTS
115 MS24693-C1 .SCR,FLH ,4-40 X3/16
(V06141) (2290200235)
***
2
120a 253E5279-00 .CRASH SURVIVABLE MEMORY A, B 1
120b 253E5279-01 .CRASH SURVIVABLE MEMORY D 1
ATTACHING PARTS
125 MS24693-C48 .SCR,PNH,8-32X3/8
(V06141) (2290200366)
6
130 MS35333-73 .WASHER,#10, INT TOOTH
(V06141) (2730200028)
6
135 MS51957-12 .SCR,PNH, 4-40 X3/16
(V06141) (2290200072)
***
2
140 189E5161-00 .PAD, CSMU, CONNECTOR, SEAL 1
145 016E5278-00 .BRACKET, BEACON, MOUNT 2
ATTACHING PARTS
150 MS16995−54 .SCREW, SCHCAP, 1/4−20 X 1−1/2
(V06141) (2290200424)
***
4
155A 266E0305-00 .BEACON, ULB, 30-DAY
FOR BATTERY REPLACEMENT ORDER
30-DAY BATTERY KIT (147E0305-00)
1
Rev.04 Page 1011
Feb. 27/14
