COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
Model FA5000
Initial Issue Page 5
Sep. 30/11
Introduction
23−70–40
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
E. CLEANING
This section contains a listing of all required cleaning materials, procedures for
cleaning material use, and applicable warnings and cautions related to the use of
prescribed cleaning solvents.
F. CHECK
This section contains the check procedures that may be required during shop main-
tenance. It covers Mechanical Inspection, Electrical Inspection and ULB Inspection
procedures.
G. REPAIR
This section contains the Model FA5000 maintenance philosophy, which provides for
Level-2 removal and replacement of failed circuit board assemblies only.
H. ASSEMBLY
This section contains detailed step-by-step procedures describing the complete as-
sembly of the Model FA5000 Solid-State Cockpit Voice Data Recorder. Each major
assembly procedure is accompanied with a line art exploded-view of the subassem-
bly area which is cross referenced to the applicable Illustrated Parts List (IPL) draw-
ing for ordering replacement parts.
I. SPECIAL TOOLS AND TEST FIXTURES
This section provides a listing of all required tools, fixtures, and equipment which are
not common maintenance tools. It also provides a description of the Read−Out
Center 6 (ROC/)/CVDR Automated Test Station (CATS) as used with the Recorder
Interface Unit (RIU) to test and download from the FA5000.
J. ILLUSTRATED PARTS LIST
This section contains parts location diagrams and parts listings for all versions of the
Model FA5000CVDR, p/n: 5001−6103-( ) with out video extension card and p/n:
5001−6133-( ) with video extension card currently produced.
The document reference is online, please check the correspondence between the online documentation and the printed version.
