COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
Model FA5000
Rev. 04 Page 103
Feb. 27/14
Testing & Fault Isolation
23–70−40
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
(1) Connect the DC power cable (17TES0412) from the DC Power connector (J8)
on the rear of the RIU to a DC power supply that can generate 28 Volts 1 Amp.
(2) Plug the cable (17TES0418) into the rear of the recorder to be tested. Plug the
SCSI connector into “Rear Connector Intfc” (J1) and plug the blue connector
into the blue “AC RCDR Power Test” (J9) connector. Both of these connectors
are on the RIU front panel.
(3) Connect the cross−over cable (024−98−00386) between the recorder front ATE
connector (J−2) and the connector in back of the ROC/7 port.
(4) Connect the USB Interface cable (17TES0415) between the RIU rear panel
connector (J4) and a USB connector on the ROC/7.
NOTE
: Note: Make the following audio connections from the RIU to
Sound Blaster sound card. Note that the sound card is lo-
cated in an expansion slot not on the motherboard.
(5) Attach the RIU Sound Card In (SND IN (J3)) cable to the Sound Card Line−In
(or Microphone−In) which is the blue connector.
(6) Attach the RIU Sound Card Out (SND OUT (J5)) cable to the Sound Card
Line−Out which is the green connector.
(7) Connect the DIN CABLE from the speakers to the middle Speaker Out (SPKRS
OUT (J6)) connector on the front panel of the RIU.
(8) After all connections are made to the RIU, apply power to the RIU. This can be
either 28Vdc.
(9) Apply power to the PC or ROC/7 and observe that the PC boots to the Win-
dows desktop.
