TPSD Control Menu Structure
Settings Menu
Float / Equalize Voltage → Float Voltage
Equalize Voltage
Equalize Timer Settings → Timer Mode
→ Timer Hours
Alarm Settings → Summary Alarm Selects → Low Current, AC Fail,
Ground Detection
→ Yes / No
Alarm Delays → Overload, End of Dis.
Ground Detection, AC, Low
Current, Low Voltage, High
Voltage, & HV Shutdown
→ 3-300 Seconds
Alarm Threshold → Low current Alarm, Low
current Alarm Reset,
Overload alarm, Overload
alarm reset, low voltage
alarm, low voltage alarm
reset, end of discharge,
end of discharge reset, high
voltage alarm, high voltage
alarm reset, & high voltage
shutdown alarm
Alarm Operation (Latching
Alarms)
→ Summary, AC Power Failure,
Low DCV, High DCV, Pos
Ground, Neg. Ground, HVSD
→
Yes / No
Ground Detection
Alarm Enable
→ Ground Detection → Yes / No
Temperature
Compensation Settings
→ Temperature
Compensation On / Off
Communication
Settings
→ See section 3.4.1.5 (The communication settings are accessible only
in units equipped with communication options 21P, 21Q, 21S
LCD Settings → LCD Backlight → Auto off 2 mins / Always On
Return to Defaults → Yes / No
Test Menu
Test LEDs → LED Test
Test Relays → Test All
Test Contacts Individually → Test Negative Ground Test
High DCV, Low DCV,
Positive Ground, AC Fail,
Summary, Low DCA
TEST HVSD → Warning: this test will
shutdown the unit and trip
the AC Breaker.
