1 Equipment Handling
1.1 Storing the TPSD
If the TPSD is to be stored for more than a few days after delivery, it should be stored within its shipping
container. The location chosen for storage should be within an ambient temperature of -40 to 185° F (-40 to
85° C) with a non-condensing relative humidity of 0 to 95%. Storage should not exceed 2 years due to the
limited shelf life of the DC filter capacitors when they are not in service.
1.2 Moving the TPSD
After careful inspection and upon verification that the TPSD is undamaged, identify the enclosure style and
weight of the TPSD unit. Refer to the tables below.
Output
Voltage
Frequency
Ampere Rating
6 ADC 12 ADC 20 ADC 25 ADC 30 ADC 35 ADC 50 ADC 75 ADC 100 ADC
24 VDC
60 Hz
4B Case 4B Case 4 Case 4 Case 4 Case 4 Case 4 Case 4 Case 9 Case
90 lbs 90 lbs 100 lbs 125 lbs 150 lbs 154 lbs 175 lbs 211 lbs 225 lbs
(40.8 kg) (40.8 kg) (45.4 kg) (56.7 kg) (68 kg) (69.9 kg) (79.4 kg) (95.7 kg) (102.1 kg)
50 Hz
4 Case 4 Case 4 Case 4 Case 4 Case 4 Case 9 Case
110 lbs 138 lbs 165 lbs 170 lbs 193 lbs 233 lbs 248 lbs
(49.8 kg) (62.6 kg) (74.8 kg) (77.1 kg) (87.5 kg) (105.7 kg) (112.5 kg)
48 VDC
60 Hz
4B Case 4B Case 4 Case 4 Case 4 Case 4 Case 4 Case 9 Case 9 Case
90 lbs 110 lbs 150 lbs 150 lbs 155 lbs 180 lbs 205 lbs 295 lbs 321 lbs
(40.8 kg) (49.9 kg) (68 kg) (68 kg) (70.3 kg) (81.7 kg) (93 kg) (133.8 kg) (145.6 kg)
50 Hz
4 Case 4 Case 4 Case 4 Case 4 Case 9 Case 9 Case
165 lbs 165 lbs 171 lbs 198 lbs 225 lbs 325 lbs 354 lbs
(74.8 kg) (74.8 kg) (77.6 kg) (89.8 kg) (102.1 kg) (147.4 kg) (160.6 kg)
130 VDC
60 Hz
4 Case 4 Case 4 Case 4 Case 9 Case 9 Case 9 Case
140 lbs 175 lbs 225 lbs 250 lbs 319 lbs 372 lbs 532 lbs
(63.5 kg) (79.4 kg) (102.1 kg) (113.4 kg) (144.7 kg) (168.7 kg) (241.3 kg)
50 Hz
4 Case 4 Case 4 Case 4 Case 9 Case 9 Case 9 Case
154 lbs 193 lbs 233 lbs 275 lbs 352 lbs 410 lbs 586 lbs
(69.9 kg) (87.5 kg) (105.7 kg) (124.7 kg) (159.7 kg) (186 kg) (265.8 kg)
Table 1 - Case Type and Weight (Single Phase, 6-100 ADC)
