14. Appendix
45
D SERIES Lake Operation Manual rev 3.0.4
14. Appendix
D SERIES Lake Operation Manual rev 3.0.3
43
D SERIES 20:4
Level Load
Rated power
per channel
Line Current Measured Power (W) Thermal Dissipation
(A) In Out Dissipated BTU/hr kCal/hr
Mains Voltage 100 VAC
Standby
0.2 7 0 7 24 6
Power On, Idling, Green Mode
0.5 46 0 46 157 39
Power On, Idling, Performance Mode
0.7 71 0 71 243 61
Pink Pseudo
Noise
16 Ω / Ch. 425 x 4 2.9 348 213 136 463 117
8 Ω / Ch. 500 x 4 3.5 418 250 168 573 144
4 Ω / Ch. 500 x 4 3.7 444 250 194 662 167
2 Ω / Ch. 500 x 4 4.1 492 250 242 825 208
100 V / Ch. 250 x 4 1.9 230 125 105 360 91
70 V / Ch. 500 x 4 3.5 410 250 160 546 138
Mains Voltage 120 VAC
Standby
0.1 7 0 7 23 6
Power On, Idling, Green Mode
0.4 45 0 45 155 39
Power On, Idling, Performance Mode
0.6 71 0 71 241 61
Pink Pseudo
Noise
16 Ω / Ch. 425 x 4 2.9 346 213 134 457 115
8 Ω / Ch. 500 x 4 3.5 411 250 161 550 139
4 Ω / Ch. 500 x 4 3.7 441 250 190 650 164
2 Ω / Ch. 500 x 4 4.1 487 250 237 810 204
100 V / Ch. 250 x 4 2.0 231 125 106 361 91
70 V / Ch. 500 x 4 3.4 408 250 158 540 136
Mains Voltage 208 VAC
Standby
0.1 7 0 7 24 6
Power On, Idling, Green Mode
0.3 43 0 43 147 37
Power On, Idling, Performance Mode
0.4 67 0 67 229 58
Pink Pseudo
Noise
16 Ω / Ch. 425 x 4 1.5 336 213 124 422 106
8 Ω / Ch. 500 x 4 1.8 398 250 148 506 127
4 Ω / Ch. 500 x 4 1.9 426 250 176 600 151
2 Ω / Ch. 500 x 4 2.1 471 250 221 753 190
100 V / Ch. 250 x 4 1.0 224 125 99 339 85
70 V / Ch. 500 x 4 1.8 395 250 145 496 125
Mains Voltage 230 VAC
Standby
0.2 7 0 7 24 6
Power On, Idling, Green Mode
0.3 43 0 43 146 37
Power On, Idling, Performance Mode
0.4 67 0 67 227 57
Pink Pseudo
Noise
16 Ω / Ch. 425 x 4 1.5 333 213 120 411 104
8 Ω / Ch. 500 x 4 1.8 394 250 144 493 124
4 Ω / Ch. 500 x 4 1.9 419 250 169 577 145
2 Ω / Ch. 500 x 4 2.1 467 250 217 741 187
100 V / Ch. 250 x 4 1.0 222 125 97 331 83
70 V / Ch.
500 x 4 1.8 392 250 142 484 122
14. Appendix
44
D SERIES Lake Operation Manual rev 3.0.3
D SERIES 40:4
Level Load
Rated power
per channel
Line Current Measured Power (W) Thermal Dissipation
(A) In Out Dissipated BTU/hr kCal/hr
Mains Voltage 100 VAC
Standby
0.2 7 0 7 24 6
Power On, Idling, Green Mode
0.6 59 0 59 201 51
Power On, Idling, Performance Mode
0.8 78 0 78 267 67
Pink Pseudo
Noise
16 Ω / Ch. 700 x 4 5.1 502 350 152 518 131
8 Ω / Ch. 1000 x 4 7.2 709 500 209 714 180
4 Ω / Ch. 1000 x 4 7.6 754 500 254 868 219
2 Ω / Ch. 800 x 4 7. 0 689 400 289 986 249
100 V / Ch. 1000 x 4 7.1 701 500 200 684 172
70 V / Ch. 1000 x 4 7.5 738 500 238 812 205
Mains Voltage 120 VAC
Standby
0.2 7 0 7 24 6
Power On, Idling, Green Mode
0.5 59 0 59 200 50
Power On, Idling, Performance Mode
0.7 77 0 77 263 66
Pink Pseudo
Noise
16 Ω / Ch. 700 x 4 4.2 497 350 147 503 127
8 Ω / Ch. 1000 x 4 5.9 700 500 199 681 172
4 Ω / Ch. 1000 x 4 6.3 743 500 243 829 209
2 Ω / Ch. 800 x 4 5.7 679 400 279 953 240
100 V / Ch. 1000 x 4 5.8 690 500 190 648 163
70 V / Ch. 1000 x 4 6.1 726 500 226 772 195
Mains Voltage 208 VAC
Standby
0.3 7 0 7 25 6
Power On, Idling, Green Mode
0.5 58 0 58 198 50
Power On, Idling, Performance Mode
0.5 77 0 77 263 66
Pink Pseudo
Noise
16 Ω / Ch. 700 x 4 2.2 486 350 136 464 117
8 Ω / Ch. 1000 x 4 3.1 681 500 181 617 155
4 Ω / Ch. 1000 x 4 3.3 723 500 223 759 191
2 Ω / Ch. 800 x 4 3.0 662 400 261 892 225
100 V / Ch. 1000 x 4 3.0 673 500 173 589 148
70 V / Ch. 1000 x 4 3.2 707 500 207 707 178
Mains Voltage 230 VAC
Standby
0.3 7 0 7 25 6
Power On, Idling, Green Mode
0.4 58 0 58 197 50
Power On, Idling, Performance Mode
0.5 77 0 77 263 66
Pink Pseudo
Noise
16 Ω / Ch. 700 x 4 2.2 474 350 124 423 106
8 Ω / Ch. 1000 x 4 3.0 664 500 164 558 141
4 Ω / Ch. 1000 x 4 3.2 705 500 205 701 176
2 Ω / Ch. 800 x 4 3.0 649 400 249 850 214
100 V / Ch. 1000 x 4 3.0 659 500 159 544 137
70 V / Ch. 1000 x 4 3.2 694 500 194 661 166
