14. Appendix
D SERIES 80:4
Level Load
Rated power
per channel
Line Current
Power
Factor
Measured Power (W) Thermal Dissipation
(A) (%) In Out Dissipated BTU/hr kCal/hr
Mains Voltage 100 VAC, 30 A
Standby 0.3 43 11 0 11 36 9
Power on, Idling 2.1 99 204 0 204 696 175
Pink Pseudo
Noise
16 Ω / Ch. 750 10.1 99 981 375 607 2070 522
8 Ω / Ch. 1500 15.3 99 1492 749 743 2534 639
4 Ω / Ch. 2000 14.9 99 1502 652 850 2900 731
2.67 Ω / Ch. 2000 15.3 99 1539 625 914 3120 787
2 Ω / Ch. 2000 15.2 99 1538 560 978 3337 8 41
LoadPilot
Sine 20 kHz
8 Ω / Ch. 2.2 98 211 0 211 720 181
M
ains Voltage 120 VAC, 30 A
Standby 0.3 35 11 0 11 37 9
Power on, Idling 1.8 98 202 0 202 689 174
Pink Pseudo
Noise
16 Ω / Ch. 750 8.0 99 954 375 579 1977 499
8 Ω / Ch. 1500 12.6 99 1476 749 727 2480 625
4 Ω / Ch. 2000 14.4 99 1739 817 923 3148 794
2.67 Ω / Ch. 2000 14.7 99 1780 766 1014 3461 873
2 Ω / Ch. 2000 15.2 99 1839 739 1101 3755 947
LoadPilot
Sine 20 kHz
8 Ω / Ch. 1.8 98 211 0 211 719 181
Mains Voltage 208 VAC, 17.3 A
Standby 0.3 17 11 0 11 39 10
Power on, Idling 1.1 91 197 0 197 673 170
Pink Pseudo
Noise
16 Ω / Ch. 750 4.6 99 927 375 552 1884 475
8 Ω / Ch. 150
0 7.1 99 1436 749 687 2345 591
4 Ω / Ch. 2000 9.3 100 1955 1000 955 3260 822
2.67 Ω / Ch. 2000 9.8 100 2087 1003 1084 3698 933
2 Ω / Ch. 2000 10.3 100 2182 1001 1181 4030 1016
LoadPilot
Sine 20 kHz
8 Ω / Ch. 1.1 92 204 0 204 695 175
Mains Voltage 230 VAC, 16 A
Standby 0.3 17 12 0 12 39 10
Power on, Idling 1.0 89 193 0 193 660 166
Pink Pseudo
Noise
16 Ω / Ch. 750 4.2 99 948 375 573 1957 493
8 Ω / Ch. 1500 6.4 99 1443 749 694 2369 597
4 Ω / Ch. 2000 8 .1 99 1907 1000 906 3092 780
2.67 Ω / Ch. 2000 8.7 100 2052 1003 1049 3580 903
2 Ω / Ch. 2000 9.4 100 2200 1000 1201 4096 1033
LoadPilot
Sine 20 kHz
8 Ω / Ch. 1.0 89 204 0 204 695 175
