R= ob^o=m^kbi=cb^qrobp=
Before turning the amplifier on please read the following sections to make sure that the unit is set up
properly for your specific application.
RKNKN= d~áå=
The gain of the fP 2400 is fixed to 32 dB
RKNKO= pÉåëáíáîáíó=
Sensitivity is defined as how many volts (rms) or dBu (referred to 0.775Vrms) are required to get full
output power. As the output power varies with the load impedance, usually 4 ohms is the reference. But
in the case of an MLS-switch equipped amplifier there are many choices for full output level in different
load impedances.
Sensitivity in Vrms
fP 2400Q
MLS SWITCH SETTING
LOAD CONFIGURATION -3 dB 0 dB
16 ohms Quad (4 channel) 0,98 1,42
8 ohms Quad (4 channel) 1,00 1,37
4 ohms Quad (4 channel) 0,98 1,33
2 ohms Quad (4 channel) 0,91
16 ohms Stereo (2 channels bridged) 0,98 1,37
8 ohms Stereo (2 channels bridged) 0,98 1,33
4 ohms Stereo (2 channels bridged) 0,90
Sensitivity in dBu
fP 2400Q
MLS SWITCH SETTING
LOAD CONFIGURATION -3 dB 0 dB
16 ohms Quad (4 channel) 2,0 5,3
8 ohms Quad (4 channel) 2,3 4,9
4 ohms Quad (4 channel) 2,0 4,7
2 ohms Quad (4 channel) 1,4
16 ohms Stereo (2 channels bridged) 2,1 4,9
8 ohms Stereo (2 channels bridged) 2,1 4,7
4 ohms Stereo (2 channels bridged) 1,3
i~ÄKÖêìééÉå== = = = = ====================== ========================S
rëÉê=j~åì~ä===Ñm=OQMM=n=====sÉêëáçå=MKU========OMMPJNMJMT=
