Hexadecimal Dump
This feature allows experienced users to see exactly what data is
coming to the printer. This can be useful in finding software
problems. When you turn on the hex dump function, the printer
prints all commands and other data in hexadecimal format along
with a guide section to help you find specific commands.
To use the hex dump feature, follow these steps:
1. After you make sure that the printer is off, open the cover.
2. Hold down the FEED button while you turn on the printer.
3. Close the cover.
4. Run any software program that sends data to the printer.
The printer prints “Hexadecimal Dump” and then all the
codes it receives in a two-column format. The first column
contains the hexadecimal codes and the second column
gives the ASCII characters that correspond to the codes.
Hexadecimal Dump
1B 21 00 1B 26 02 40 40 ← ! ← & ☻ @ @
1B 25 01 1B 63 34 00 1B ←%☺← c
4
←
41 42 43 44 45 43 47 48 ABCDEFGH
5. Close the cover and turn off the printer or reset it to turn off
the hex dump mode. (or to terminate hex dump, press FEED
button three times, and when you see
*** completed ***, the hex dump mode was turned off.
4-6
APPENDIXES
APPENDIX A
Dip Switch and Paper Near End Settings
Although the factory settings are best for almost all uses, if you have
special requirements, you can change the DIP switch or paper near
end settings.
Setting the DIP Switches
DIP switch functions
Your printer has three sets of DIP switches. The functions of the
switches are shown in the following tables.
Serial interface specification
Set 1
Dip Switch and Paper Near End Settings
A–1
SW Function ON OFF
1-1
Print emulation TM200 EPSON Emulation
1-2
Paper near end sensor Vertical Horizontal
1-3
1-4
Selects print density Refer to page ‘A-3” table
1-5
Cutter setting Disable Enable
1-6
Stop bit 2 bit 1 bits
1-7
Cutter mode Full Partial
1-8
Reserved: do not
change settings
Fixed to OFF
To Next Page
