LOGIC BOARD
3-18
REMOTE TRIGGER CONNECTOR
(PRODUCT SWITCH)
P1
PIN #
I/O
ADDRESS
TRIGGER INPUT
1
INPUT
P3.4
+24 VOLT
2
24V COMMON
3
SHIELD
HEAD-UP / AUX IN
P2
PIN #
I/O
ADDRESS
HEAD-UP
1
INPUT
P3.5
+24 VOLT
2
24V COMMON
3
SMART TAMP / AUX IN 1
4
INPUT
P3.6
5
SHIELD
AUX 2
P3
PIN #
I/O
ADDRESS
+5dvc
1
(GND)
2
3
PRE-PRINT INPUT
4
INPUT
P3.7
24V COMMON
5
+24 VOLT
6
SHIELD
TAMP SOLENOIDS
P4
PIN #
I/O
ADDRESS
1
+24 VOLT
2
3
AIR ASSIST SOL 24VDC
4
OUTPUT
P2.5
VACUUM SOL 24VDC
5
OUTPUT
P2.4
TAMP SOL 24VDC (also MTR2 120vac)
6
OUTPUT
P2.6
FLAG SOL 24VDC
7
OUTPUT
P2.7
SHIELD
