LabelMill LM3605 - Page 47

LM-3605 Dynamic Label Applicator
USERS MANUAL
Page 47 Made in the U.S.A.
© 2019 LABELMILL
12/01/2019 Model LM3605
3-19
WARNING BEACON / AUX
P5
PIN #
I/O
ADDRESS
LOW LABEL PHOTOEYE 24VDC
1
INPUT
P1.5
+24 VOLT
2
24V COMMON
3
RUN STATUS (OK) 24VDC (green light)
4
OUTPUT
P1.3
No connection
5
LOW RIBBON / LABEL 24VDC
(yellow light)
6
OUTPUT
P1.4
ERROR LITE 24VDC (red light)
7
OUTPUT
P1.3
DISABLE LABELER
8
INPUT
P1.7
SHIELD
PRINT AND APPLY INTERFACE
P6
PIN #
I/O
ADDRESS
PAPER END
1
INPUT
P0.0
PRINTER GROUND
2
RIBBON END
3
INPUT
P0.1
PRINTER ERROR
4
INPUT
P0.2
PRINT START
5
OUTPUT
P0.7
PRINT END
6
INPUT
P0.4
REPRINT
7
OUTPUT
P0.6
8
ONLINE
9
INPUT
P0.5
10
RIBBON NEAR END
11
INPUT
P0.3
12
+5vdc from printer
13
SHIELD
TAKE-UP MOTOR /
ROUND MODULE
P7
PIN #
I/O
ADDRESS
1
2
MOTOR 2 NEUTRAL
3
4
MOTOR 1 120VAC (take-up / round
module)
5
OUTPUT
P1.6
MOTOR 2 120VAC (auto-round)
6
OUTPUT
P2.6 / Tamp
7
8
GND / SHIELD
