MSD Legend Series Operation & Maintenance Manual | 27
Curl the Shear Under
FIGURE 20
Loosening Blades
1. Back out the bolts holding the blade in place. Ensure the bolts are still threaded into the blade.
Never strike the blade with a hardened steel tool. The
blade may chip and cause severe injury.
2. If the blades are not loose, tap on the blade face with a soft-faced mallet.
3. Use a pry bar between the blade and blade seat to loosen the blade.
Do not strike the blade bolts directly with a hammer or
other hard object. This may cause damage to the blade.
4. If the blade is still not loose, place a wood block against the head of one of the blade bolts. Strike it with a mallet.
Bolts are loose,
but threaded in
the blade.
Loosen the Blades
FIGURE 21
