MSD Legend Series Operation & Maintenance Manual | 37
3. Place the shear upside down so that the upper blades
are as close to the ground as possible. Remove the
upper blades.
4. With the shear still upside down, remove both piercing
tips. Clean the mating surface of the blade seats, as
shown in “3rd Rotation” on page 36. Replace with
new tips. Replace upper blades at this time.
5. Rotate the attachment so the lower jaw is on the
ground. Torque the upper blades and tip as shown in
“Inspect / Torque Bolts” on page 25.
