Lainox SAPIENS SAGB071 User Manual

36
90027911rev04
13 • OPERATING AT THE RATED HEAT OUTPUT
Select the burner, by turning knob 16 and confirm by
pressing knob 16.
To change a value, highlight it by turning knob 16
and confirm by pressing knob 16.
Set the new value, by turning knob 16 and confirm by
pressing knob 16.
Proceed in the same way to change the values of the
other burners if present (example “Chamber burner
2”).
A2
A1
1
4
5
8
9
12
13
14
3
6
10
15
2
7
11
16
1
2
3
4 5 8 9 1312 14
76 1510 11 16
