Lake LM Series User Manual

Signal Flow and Lake Processing
11
Lake LM Series Operation Manual Rev 1.3.5
5. Signal Flow and Lake Processing
5.1 Signal Flow
The gures below depict the audio signal ow for LM Series devices congured in both Contour and Mesa
modes. It is worth noting that this sophisticated device provides up to ve points in the signal chain where
the signal level can be adjusted, muted or disconnected (depending on whether congured in Contour or
Mesa Mode as described below). The blue sections represent Frame data, and the red sections represent
Module data - please refer to the Lake Controller Operation Manual for further information.
Important information regarding correct setting of the gain structure can be found in section 9.1.
Figure 5-1: LM Series Signal Flow (Contour Mode)
