This single DB25 connection provides four channels of AES3 input and eight channels of AES3 output as
shown in Figure 7-5 on page 43 below. A detailed wiring reference is provided in Figure 7-9.
AES3 Inputs AES3 Outputs
AES1: Ch. 1 & 2 AES1: Ch. 1 & 2
AES2: Ch. 3 & 4 AES2: Ch. 3 & 4
AES3: Ch. 5 & 6* AES3: Ch. 5 & 6
AES4: Ch. 7 & 8* AES4: Ch. 7 & 8
*LM 44 Only
Table 7-1: DB25 Input and Outputs
Figure 7-9 below provides a wiring reference for the DB25 connector.
Ch. Ground Hot Cold
1/2 IN 10 1 14
3/4 IN 11 2 15
5/6 IN 12 3 16
7/8 IN 13 4 17
1/2 OUT 22 5 18
3/4 OUT 23 6 19
5/6 OUT 24 7 20
7/8 OUT 25 8 21
Figure 7-9: DB25 Wiring Reference
Figure 7-5 on page 43 shows the only possible method of wiring; there is no equivalent of an unbalanced
connection in the digital domain.
7.3 RJ45 etherCON Network Connections
Two RJ45 etherCON style network connections are provided as shown in Figure 7-10.
