In Mesa Mode, a Module can be connected to any of the eight input routers, providing four stages of mute/
connectivity (stage 1,2,4 & 5).
If the required audio signal is not passing correctly,
verify the connection, mute and gain settings at all
ve stages.
5.3 Lake Processing and Control
As outlined in section 2.2.1, this device integrates seamlessly into the Lake Processing environment,
providing all features, functionality and connectivity associated with all Lake Processors. The internal Lake
Processing includes programmable crossovers, EQ, dynamics and other functions, and can be fully con-
trolled via the supplied Lake Controller software. Additionally, many functions can be controlled or accessed
directly via the front panel.
The Lake Controller Operation Manual and Lake Network Conguration Guide are supplied on the accom-
panying CD-ROM or USB key and additional documentation is available from the Start Menu after software
installation.
Visit http://lakeprocessing.com to download the latest software, rmware and documentation for your
devices.
5.4 Modules and Frames
5.4.1 Overview
A Frame represents one physical Lake Processor (e.g. LM 26 or LM 44). In Contour Mode, a maximum
of two Modules are contained within each Frame; these are referred to as Module A and Module B. The
number of Modules shown in a given Frame is also dependent upon the signal processing conguration of
that Frame. In Mesa Mode each Frame contains four Modules labelled A, B, C & D.
In Contour Mode, each Module can be congured as a Classic Crossover (Bessel, Butterworth, Linkwitz-
Riley), as a Linear Phase Crossover, or as multiple full bandwidth Auxiliary Outputs. The default conguration
for the LM 26 is 2 x Classic 3-Way Modules, providing a total of six Module outputs. The default congura-
tion for an LM 44 is four Mesa EQ Modules, providing a total of four Module outputs.
Please refer to the Lake Controller Operation Manual for further information.
