Signal Flow and Lake Processing
15
Lake LM Series Operation Manual Rev 1.3.5
5.7 Switching between Contour and Mesa Mode
When switching between Contour and Mesa Modes, all current Frame conguration data is lost (Presets
are retained) and the device is completely recongured into the selected Mode. Ensure you have stored any
existing frame conguration data before conguring into a different mode.
The device conguration may be changed either via the Front Panel MENU > FRAME > FRAME RST (refer
to section 6.10.4.2) or via the Lake Controller MODULES > I/O CONFIG > FRAME CONFIG menu (refer to
the Lake Controller Operation Manual).
5.8 Files and Presets
The Lake system provides various methods for storing and recalling Module, Frame, or system-wide data.
An overview is provided below; for further information please refer to the Lake Controller Operation Manual.
5.8.1 Module, System and Sub-System Conguration Files
Module, System and Sub-System Conguration les are stored on the Lake Controller PC, and data is
passed across the network when recalling or storing these type of les.
▸ A Module le is the smallest set of data that can be stored and recalled; it contains crossover, gain,
delay, and limiter information for an individual loudspeaker (i.e. the data shown in red in the signal ow
diagrams in section 5.1). A Module le may be recalled into other Lake devices. It is not possible to
store a Module File directly on the hardware device.
▸ A System or Sub-System Conguration File contains a set of Module le information in addition to
Frame related information such Group data and I/O conguration (i.e. the data shown in blue in the
signal ow diagrams in section 5.1).
5.8.2 Frame and System Presets
The entire processor conguration can be stored as a Frame Preset on this hardware device. Presets can
be recalled via the front panel (refer to section 6.10.6) or via the Lake Controller software or Preset Manager
utility; presets can be stored using the Lake Controller software or Preset Manager utility.
A maximum of 100 Frame Presets can be stored on this device. The data within a Frame Preset includes the
congurations of all Modules in the Frame, including levels, crossover, EQ, input mixer, routing, and all other
parameters. As Frame Presets are stored in the hardware device, recall is available without using a PC.
Using the System Presets function in the Lake Controller, entire system congurations can be stored and
recalled across a network of LM & PLM Series devices. This enables fast retrieval and switching of entire
system congurations as minimal data is being sent between the Controller and Processors.
