Driving
1
Coolant temperature gauge
2
Fuel gauge
3
Driver Information System
4
Indicator lights bar
The indicator lights are also
shown in the central area of
the instrument cluster and in
the status bar
Instrument cluster
On starting the vehicle, the driving
mode selected is always STRADA
with the gearbox in D.
21
3 3
3
4
5
6
8
9
7
10 11
12
5
Range Bar
Telephone Signal Bar
6
Revolution counter
7
Engaged gear and gearbox mode
With the gearbox in the M mode, the previous and next gear are
displayed, along with the gear shifting assistance arrows
8
Selected driving mode
In CORSA driving mode with the gearbox in M, the gear shifting
assistance LEDs are also displayed
9
Speedometer Readout
10
Engine oil temperature gauge
11
BOOST indicator
12
Status Bar
The status bar shows the clock, the outside temperature and the total/
partial mileometer (when the Vehicle Functions tab is displayed in the
driver information system).
