14_
Installation above an oven
If the appliance is installed with an oven
underneath, please leave at least 15mm of
ventilation, unless otherwise stated in your
oven
installation guidelines.
Installing the product - Self adhesive seal
Turn the hob underside down, place it on a
.ecafrus detcetorp ta lf
Apply the self adhesive seal to the
underside edges of the hob glass. For best
results, the seal should be adhered along
each side in turn, as close to the edge as
possible, and trimmed at each corner, taking
care to ensure a neat join.
DO NOT eht rednu tnalaes enocilis t if
glass hob instead of the self-adhesive seal.
Worktop
15mm
Oven
Hob
5mm
Before installation
Installation
If the installation is n
Gently insert hob into cut out, allowing clips to
hold the hob in place.
ot above an oven and the
underside of the hob is accessible, a wooden shield
is required to be installed at least 15mm below the
underside of the hob unit.
15 min.
