11 Dimensions and technical data
Issue EN 2022/05 PUK 6 Operating manual
52/56
11.2 Technical data for the device
Name Value Unit
Electrical connection
Voltage
(supply)
3L+N+PE 400/230 V AC
L+N+PE 230 V AC
Frequency 50 Hz
Fuse/breaker protection provided by the operator
Tripping characteristics:
B
Power consumption 1000 W
Max. current strength 4.4 A
Breaking capacity 6 kA
Protection class per EN 61140:2016 Protection class I
General data
Max. operating temperature 60 °C
Max. outside temperature Transport/storage -20 - +55 °C
Operation -10 - +40 °C
Relative humidity Up to 50 % at 40 °C
Up to 90 % at 20 °C
Max. location altitude (above sea level) 1000 m
Protection type per EN 60529:2014 IP21S
Shielding gas Argon
Tab. 11.2 Technical data for the machine
