43Landa ENG Dealer’s Manual 9.801-510.0 - AV
Burner - NG 4-5
NG 4-2000, 4-2200, 4-3000, 5-2300, 5-3000
REF PART NO. QTY DESCRIPTION NOTES
1 8.718-055.0 1 BURNER RING X 44 W/# 54 NOZZLES
(4-2, 4-22, 4-3 NATURAL GAS)
- 8.725-894.0 1 BURNER RING X 44 W/# 52 NOZZLES
(5-23, 5-3 NATURAL GAS)
- 8.718-060.0 1 BURNER RING X 44 W/# 63 NOZZLES
(4-2, 4-22, LP)
- 8.753-526.0 1 BURNER RING X 44 W/# 69 NOZZLES
(5-23, 5-3 LP)
2 9.803-560.0 1 SCREW, 3/8" X 2" WHIZ LOC
3 8.920-698.0 1 SPACER, BRACKET, RING NG/SM
4 9.802-781.0 1 NUT, 3/8" WHIZ LOC
5 8.920-697.0 1 BRACKET, BURNER RING NG/SM
6 9.803-561.0 1 NIPPLE, 3/4" X 5" BLACK PIPE
7 9.802-027.0 2 ELBOW, 3/4" 90°, PIPE
8 9.802-019.0 2 NIPPLE, 3/4" X 2" BLACK PIPE
9 9.802-049.0 2 UNION, 3/4" BLACK PIPE
10 9.802-021.0 1 NIPPLE, 3/4" X 9" BLACK PIPE
11 8.706-184.0 2 ELBOW, 3/4" STREET, PIPE
12 8.753-465.0 1 NIPPLE, 3/4" X 14" BLACK PIPE
13 9.803-616.0 1 VALVE, 3/4" NG, 24V, HONEYWELL
14 9.802-017.0 1 NIPPLE, 3/4" X CLOSE
15 8.921-410.0 1 ROD, .625 X 4.250
16 8.921-392.0 1 BRACKET, HINGE
17 9.803-551.0 1 SCREW, 5/16 WHIZ LOC
18 8.718-897.0 1 NUT, 5/16 EXTRUDED
19 8.718-870.0 2 NUT, 5/8 PUSH
20 9.802-718.0 1 U-BOLT 5/16 X 1
21 8.706-319.0 1 NIPPLE, 1/2 JIC X 1/2 FPT
22 9.802-911.0 36 TUBING, ALUMINUM
23 8.918-425.0 1 HOSE, 3/8 X 29"
24 9.802-015.0 1 NIPPLE, 1/2" X 4" PIPE
25 8.753-397.0 4 RIVET, 1/4" PRST
