Landa ENG4-2000 - Float Tank - NG 6-10

55Landa ENG Dealer’s Manual 9.801-510.0 - AV
Float Tank - NG 4-5
NG 4-2000, 4-2200, 4-3000, 5-2300, 5-3000
REF PART NO. QTY DESCRIPTION NOTES
1 9.802-259.0 44" HOSE, 1/2" PUSH-ON
2 9.802-151.0 2 SWIVEL, 1/2" BARB X 1/2" JIC
3 9.802-261.0 38" HOSE, 3/4" PUSH-ON
4 9.802-050.0 1 ELBOW, 3/4" BARB X 3/4" MPT
5 9.802-129.0 1 ELBOW, 1/2" MSAE X 3/8" MPT, BRASS
6 8.750-743.0 2 BULKHEAD, 1/2" POLYPRO
7 8.707-310.0 1 VALVE, FLOAT BRASS
8 8.707-311.0 1 ADAPTER, FLOAT VALVE
9 8.921-824.0 1 TANK, FLOAT, 2.6 GAL. W/HOLES
10 9.802-252.0 2 HOSE, 1/4" BRAIDED VINYL
11 9.802-695.0 2 NUT, 10/32" KEPS
12 9.802-764.0 2 SCREW, 10/32" X 3/4" HEX
13 9.802-259.0 19" HOSE, 1/2" PUSH-ON
14 9.802-151.0 2 SWIVEL, 1/2" BARB X 1/2" JIC FEM
15 9.802-128.0 2 NIPPLE, 1/2" JIC X 1/2" MPT, PIPE
16 8.707-061.0 1 STRAINER, 1/2" BASKET
17 9.802-052.0 BULKHEAD, 3/4" POLYPR
18 8.709-369.0 1 CHECK VALVE PVC 1/4 BARB X BAR
19 6.390-126.0 1 CLAMP, HOSE, .46-, .54 ST
