Landa ENG4-2000 - Panels & Doors - NG 6-10

81Landa ENG Dealer’s Manual 9.801-510.0 - AV
Panels & Doors - NG 4-5
NG 4-2000, 4-2200, 4-3000, 5-2300, 5-3000
REF PART NO. QTY DESCRIPTION NOTES
1 8.921-402.0 1 PANEL, TOP
2 8.753-255.0 8 NUT, EXTRUDED U-NUT
3 8.726-103.0 8 SCREW, 1/4 X 5/8 WHIZ LOC
4 8.753-493.0 1 START COLLAR
5 9.800-006.0 1 HOT/CALIENTE
6 9.800-034.0 1 CLEAR LEXAN
7 9.800-013.0 1
LABEL, ASSEMBLED USA
INTENDED FOR INDOOR USE
8 8.932-965.0 1 LABEL, WARNING EXPOSED PULLEYS
9 8.900-990.0 1 LABEL, INSTRUCTIONS/WARNING
10 9.800-016.0 1 LABEL, DISCONNECT POWER
11 8.916-090.0 1 LABEL, LANDA
12 8.900-207.0 1 LABEL, INCOMING POWER
13 8.932-964.0 1 LABEL, NATURAL GAS
14 9.800-020.0 1 LABEL, COLD WATER INLET
15 9.800-021.0 1 LABEL, HOT WATER OUTLET
16 9.800-049.0 1 LABEL, MANUFACTURER'S CLEANING SOLUTION
17 8.921-400.0 1 DOOR, CONTROL NG/SM
18 8.921-398.0 2 DOOR, END PANELS NG/SM
19 8.921-399.0 3 DOOR, SIDE PANEL COIL PUMP
20 8.753-254.0 1 BALL STUD, LARGE, 5/16 ZINC
21 9.802-778.0 12 NUT, 5/16, WHIZ LOC FLANGE
22 9.802-068.0 12 PLUG, RUBBER
23 8.719-081.0 6 LATCH SPRING, FLUSH HEAD
24 8.753-462.0 12 RIVET, 1/8" BLACK STEEL
