Landa ENG4-2000 - Tensioner - NG 6-10

63Landa ENG Dealer’s Manual 9.801-510.0 - AV
Tensioner - NG 4-5
NG 4-2000, 4-2200, 4-3000, 5-2300 5-3000
REF PART NO. QTY DESCRIPTION NOTES
1 9.802-380.0 1 PULLEY, BK 80 H (4-2000)
- 9.802-391.0 1 PULLEY, 2BK 100 H
(4-2200A, B, C, G, H,
4-3000, 5-2300)
- 9.804-060.0 1 PULLEY, 2BK 65 H (5-3000)
- 9.803-299.0 1 PULLEY, 2BK57H (4-2200F)
2 8.715-560.0 1 PULLEY, BK 30 H (4-2000)
- 9.802-383.0 1 PULLEY, 2BK 36 H
(4-2200A, B, C, G, H,
4-3000, 5-2300)
- 8.715-582.0 1 PULLEY, 2BK 47 H (5-3000)
- 9.802-384.0 1 PULLEY, 2BK40H (4-2200F)
3 9.802-402.0 1 BUSHING, H X 24MM
4 9.802-400.0 1 BUSHING, H X 1-1/8"
(4-2200A, B, C, G, H,
4-3000, 5-2300)
- 9.803-897.0 1 BUSHING, H X 3/4" (4-2000)
- 9.802-401.0 1 BUSHING, H X 1-3/8" (4-2200F, 5-3000)
5 9.802-744.0 4 BOLT,10MM X 20MM HH ZINC
(4-2200, 4-3000,
5-2300, 5-3000)
- 9.802-741.0 4 BOLT, 8MM X 16MM (4-2200)
6 8.718-961.0 4 WASHER, M10 SPLT RING LCK8.8 CLSS ZINC PLTD
(4-2200,4-3000,
5-2300, 5-3000)
- 9.802-813.0 4 WASHER, 5/16 SPLT RING (4-2000)
7 8.715-705.0 1 BELT, BX44 (4-2000)
- 8.715-708.0 2 BELT, BX48
(3.9/30, 4.0/22A,
B, C, G, H)
- 8.715-701.0 - BELT, BX40 (4.0/22F)
- 8.715-707.0 2 BELT, BX47 (5-2300)
- 8.715-702.0 2 BELT, BX41 (5-3000)
8 9.802-767.0 2 SCREW, 3/8" X 3/4" NC WHIZ LOC FLANGE
9 8.923-700.0 1 BRACKET, TENSIONER, ROSTA
10 8.749.975.0 1 TENSIONER, ROSTA
11 8.749-973.0 1 BUSHING, IDLER TENSIONER
12 8.753-273.0 1 PULLEY, 2B36 SH
(4-2200, 4-3000,
5-2300, 5-3000)
- 8.715-578.0 1 PULLEY, 1B36 SH (4-2000)
13 9.802-781.0 2 NUT, 3/8" NC WHIZ LOC FLANGE
14 8.921-205.0 1 LABEL, MOTOR ROTATION
15 9.802-778.0 3 NUT, 5/16" WHIZ LOC FLANGE
16 8.921-393.0 1 BRACKET, PULLEY TENSIONER,NG/SM
17 8.718-625.0 3 BOLT, 5/16"- 18 X 3/4" CRRG
