45Landa ENG Dealer’s Manual 9.801-510.0 - AV
Coil - NG 4-5
NG 4-2000, 4-2200, 4-3000, 5-2300, 5-3000
REF PART NO. QTY DESCRIPTION NOTES
1 8.753-493.0 1 START COLLAR 10"
2 8.930-140.0 1 INSULATION, TOP HEAD,
3 8.921-388.0 1 RETAINER, INSULATION COIL TOP
4 8.753-466.0 1 INSULATION, BLANKET
5 8.921-380.0 1 WLMT, COIL, 20" GAS NG/SM
6 9.802-767.0 3 SCREW, 3/8 X 3/4 WHIZ LOC
7 9.802-781.0 3 NUT, 3/8 NC WHIZ LOC
8 8.707-381.0 1 RUPTURE DISC ASSY, 8500#
9 9.149-003.0 1 MANIFOLD COIL OUTLET DISCHARGE
10 9.802-024.0 1 ELBOW, 3/8" MPT X 1/2" FPT STREET, STEEL
11 8.706-248.0 1 PLUG, 3/8" ALLEN
12 9.196-012.0 1 SCREW, 10-24 X 1/4" HEX
13 8.707-019.0 1 PUSH-ON 1/2" BARB X 3/8 MPT
14 9.802-259.0 40" HOSE 1/2" PUSH-ON
15 8.706-167.0 1 ELBOW, 3/8" FPT, 90 DGR, P/N-TF3509X6
16 8.715-967.0 36" WIRE, NTW 16 GA, GREEN
17 8.726-103.0 4 SCREW, 1/4"-20 X 5/8" WHIZ LOC
18 9.802-775.0 4 NUT, 1/4" WHIZ LOC
19 9.802-171.0 1 COUPLER, 3/8 PLUG MALE
20 8.706-294.0 1 BUSHING 1/2" X 3/8" STEEL
21 8.912-530.0 2 WLMT, PLATE DISCHARGE COUPLING
22 9.802-014.0 1 NIPPLE, 1/2" X 3"
23 9.802-043.0 1 ELBOW, 1/2" JIC X 1/2" FEM
24 8.918-211.0 1 HOSE, 3/8 X 40", 2-WIRE
25 9.802-146.0 1 SWIVEL, 1/2" X MP 3/4" GHF
26 9.802-128.0 1 NIPPLE, 1/2" X JIC 1/2" MPT
27 8.921-411.0 1 SHIELD, PILOT , NG/SM
28 9.802-685.0 1 PILOT,NATURL GAS PILOT A3-S,#77623 2SH60
29 9.802-772.0 2 SCREW, 10/32" X 1/4"
30 8.726-103.0 2 SCREW, 1/4"-20 X 5/8" WHIZ LOC
31 8.718-817.0 2 NUT, 1/4" WHIZ LOC SS
32 9.802-036.0 1 NIPPLE, 1/2" JIC X 3/8" MPT, STEEL
