53Landa ENG Dealer’s Manual 9.801-510.0 - AV
Coil - NG 6-10
NG 6-3200, 8-3200, 10-3000
REF PART NO. QTY DESCRIPTION NOTES
1 8.753-494.0 1 START COLLAR 12"
2 8.753-549.0 1
INSULATION, TOP HEAD, 30"OD X 12"ID
FIBERGLASS
3 8.921-650.0 1 RETAINER, INSULATION COIL TOP, NG/LM
4 8.753-540.0 1 INSULATION, BLANKET 1" THK X 39" W X 90" L
5 8.912-039.0 1 WLMT, COIL ASSY, HSS 28"
6 8.921-411.0 1 SHIELD, PILOT, NG/LM
7 9.802-685.0 1 PILOT,NATURL GAS PILOT A3-S,#77623 2SH60
8 8.921-709.0 1 ADAPTER PLATE, PILOT ASSY (6-32)
9 8.726-103.0 2 SCREW, 1/4-20 X 5/8", WHIZ LOC BLACK CAD
10 8.706-172.0 1 ELBOW, 1/2 FEM 90°
11 8.706-236.0 1 TEE, 1/2", STREET-P/N-TF3759X8
12 9.802-015.0 1 NIPPLE, 1/2" X 4 GALV SCH 80 MPT
13 8.912-530.0 2 WLMT, PLATE DISCHARGE COUPLING VNG
14 8.712-187.0 1 SWITCH, SNAP, 275 DR HI-LIMIT
15 9.802-260.0 1 HOSE 5/8"
16 9.802-024.0 1 ELBOW, 3/8" MPT X 1/2" FPT STREET, STEEL
17 8.707-381.0 1 RUPTURE DISC ASSY, 8500#
18 9.803-559.0 1 CLAMP,SCREW,9/16"W, 1-1/4"OD, SS
19 9.802-036.0 1 NIPPLE, 1/2" JIC X 3/8" MPT, STEEL
20 8.715-967.0 5 WIRE, MTW 16 GA, GREEN/FT
21 9.802-772.0 2 SCREW, 10/32" X 1/4", HWH ROLOC, ZN
22 9.802-911.0 24 TUBING, ALUMINUM, 600"/RL1/4" 37-961464, PER
23 9.802-775.0 2 NUT, 1/4" FLANGE, ZN
24 8.706-248.0 1 PLUG, 3/8" ALLEN COUNTER SUNK
25 9.149-003.0 1 MANIFOLD COIL OUTLET DISCHARGE 1
26 9.802-043.0 1 ELBOW, 1/2" JIC X 1/2" FPT
27 9.802-014.0 1 NIPPLE, 1/2" X 3"
28 8.918-230.0 1 HOSE, 1/2" X 70" 2 WIRE
29 9.196-012.0 1 SCREW, 10/24" X 1/4"
30 9.802-781.0 1 NUT, 3/8" WHIZ LOC
31 8.921-709.0 1 ADAPTER PLATE, PILOT ASSY (6-32)
