57Landa ENG Dealer’s Manual 9.801-510.0 - AV
Float Tank - NG 6-10
NG 6-3200, 8-3200, 10-3000
REF PART NO. QTY DESCRIPTION NOTES
1 9.802-261.0 15 HOSE, 3/4" PUSH-ON, /FT
2 9.802-152.0 3 SWIVEL, 3/4" SAE FEM, PUSH-ON
3 9.803-557.0 1 ELBOW, 3/4" MSAE X 3/4" MPT, BRASS
4 9.802-252.0 6 HOSE, 1/4" X 1/2" BRAIDED VINYL,/FT
5 8.921-825.0 1 TANK, PLASTIC, 8 X 16 X 24
6 8.706-794.0 2 NIPPLE, 1/2" X 1/4" MODIFIED (6-3200)
- 8.706-780.0 2 NIPPLE, 1/4" HEX (8-3200), (10-3000)
7 8.707-061.0 2 STRAINER, 1/2" BASKET (6-3000)
- 8.707-076.0 2 STRAINER, 1/4" BASKET (8-3200), (10-3000)
8 8.706-925.0 2 BUSHING, 3/4" X 1/2" (6-3200)
- 8.706-923.0 2 BUSHING, 3/4" X 1/4" (8-3200), (10-3000)
9 8.749-329.0 1 VALVE, FLOAT 3/4" KERICK
10 8.706-512.0 1 BALL, FLOAT, BLACK PLASTIC
11 8.719-648.0 1 ROD, THREADED, 1/4" X 6" BRASS
12 9.802-753.0 4 SCREW, 1/4"-20 X 3/4" WHIZ LOC
13 9.802-050.0 1 ELBOW, 3/4" BARB X 3/4" MPT PVC
14 8.706-899.0 1 NIPPLE, 3/4" JIC X 3/4" PIPE
15 9.803-557.0 1 ELBOW, 3/4" MSAE X 3/4" MPT, BRASS
16 9.802-052.0 3 BULKHEAD, 3/4" POLYPRO
17 8.709-369.0 1 CHECK VALVE PVC 1/4 BARB X BAR
18 6.390-126.0 1 CLAMP, HOSE, .46-, .54 ST
