59Landa ENG Dealer’s Manual 9.801-510.0 - AV
Pump - NG 4-5
NG 4-2000, 4-2200, 4-3000, 5-2300, 5-3000
REF PART NO. QTY DESCRIPTION NOTES
1 8.706-984.0 1 ADAPTER 1/2" FPT X 1/2" MPT
2 9.803-050.0 1 TEE, 1/2" STREET W/2 HOLES
3 9.802-128.0 2 NIPPLE, 1/2" JIC X 1/2" MPT
4 9.802-151.0 1 SWIVEL, 1/2" BARB X 1/2" JIC FEM
5 9.802-259.0 15" HOSE, 1/2" PUSH-ON
6 8.706-864.0 1 PLUG, 1/8" COUNTERSUNK
7 8.706-965.0 1 HOSE BARB, 1/4" BARB X 3/8" MPT 90°
8 6.390-126.0 2 CLAMP, HOSE, .46 -.54 ST
9 9.802-252.0 24" HOSE, 1/4 X 1/2 BRAIDED VINYL/FT
10 9.802-632.0 1 CAP, VALVE 24MM W/1/4" GAUGE PORT
11 9.802-458.0 1 SWITCH, PRESSURE N/O NPT
12 9.802-048.0 1 SWIVEL, 1/2" JIC FPT X 3/8" MPT
13 9.802-036.0 1 NIPPLE, 1/2" JIC X 3/8" MPT STEEL
14 8.750-955.0 1 UNLOADER, VRT3 W/SWITCH
15 9.802-039.0 1 ELBOW, 1/2" JIC X 3/8" MPT, STEEL
16 9.802-129.0 1 ELBOW, 1/2" JIC X 3/8" MPT
17 8.918-425.0 1 HOSE, 3/8" X 29"
18 8.706-955.0 1 HOSE BARB, 1/4" X 1/8" MPT, 90°
19 - - - SEE SPECIFICATIONS
