61Landa ENG Dealer’s Manual 9.801-510.0 - AV
Pump - NG 6-10
NG 6-30200, 8-3200, 10-3000
REF PART NO. QTY DESCRIPTION NOTES
1 9.802-261.0 18" HOSE, 3/4" PUSH-ON
2 9.802-152-0 2 SWIVEL, 3/4" SAE FEM PUSH-ON
3 8.752-090.0 1 ELBOW, 3/4" MSAE X 1/2" MPT, BRASS, W/1/8" TAP
4 8.753-727.0 1 UNLOADER, VRT100 W/SWITCH
5 9.802-252.0 1 HOSE, 1/4" X 1/2" BRAIDED VINYL 1
6 8.706-315.0 1 SWIVEL 1/2" JIC FPT, 1/2" MPT, STEEL
7 9.802-040.0 1 ELBOW, 1/2" JIC X 1/2" MPT, STEEL
8 8.706-899.0 3 NIPPLE, 3/4" JIC X 3/4" PIPE
9 8.706-852.0 1 CROSS, 3/4" FEMALE PIPE P/N-3950-12
10 8.706-923.0 2 BUSHING, 3/4" X 1/4" BRASS
11 8.706-865.0 1 PLUG, 1/4" NPT COUNTER SUNK
12 8.706-800.0 2 NIPPLE, 3/4" HEX, BRASS (8-3200,10-3000)
- 8.706-881.0 2 NIPPLE, 3/4" X 1/2" MPT (6-3200)
13 8.706-846.0 1 TEE, 3/4" FEMALE PIPE BRASS
14 9.802-458.0 1 SWITCH, PRESSURE N/O 1/4 NPT SS
15 8.706-958.0 1 HOSE BARB X 1/4" MPT 90°
16 6.390-126.0 2 CLAMP, HOSE, .46 -.54 ST
17 - - - SEE SPECIFICATIONS
18 8.706-282.0 1 BUSHING, 1/2" X 1/4" STEEL (8-3200,10-3000)
- 8.706-297.0 1 BUSHING, 3/8" X 1/4" STEEL (6-3200)
19 9.802-038.0 1 NIPPLE, 1/2" JIC X 1/2" MPT, STEEL (8-3200,10-3000)
- 9.802-036.0 1 NIPPLE, 1/2" JIC X 3/8" MPT, (6-3200)
20 8.706-955.0 1 HOSE BARB, 1/4" BARB X 1/8" MPT 90°
