65Landa ENG Dealer’s Manual 9.801-510.0 - AV
Tensioner - NG 6-10
NG 6-3200, 8-3200, 10-3000
REF PART NO. QTY DESCRIPTION NOTES
1 8.715-617.0 1 PULLEY, 38K 70 H (6-3200, 10-3000)
- 8.715-618.0 1 PULLEY, 38K 80 H (8-3200)
2 8.715-607.0 1 PULLEY, 3TB60 (6-3200, 10-3000)
- 8.715-608.0 1 PULLEY, 3TB62 (8-3200)
3 8.715-611.0 1 PULLEY, #B365SH
4 9.802-403.0 1 BUSHING, H X 25MM
5 9.803-980.0 1 BUSHING, P1 X 1-5/8"
6 8.715-706.0 3 BELT, BX46 (6-3200,10-3000)
- 8.715-708.0 3 BELT, BX48 (8-3200)
7 8.921-648.0 1 BRACKET, PULLEY TENSIONER, LG/LM
8 9.802-722.0 1 BOLT, 3/8" X 1-1/4" NC HH
9 9.802-781.0 2 NUT, 3/8" NC, WHIZ LOC FLANGE
10 8.923-700.0 1 BRACKET, TENSIONER, ROSTA
11 8.749-975.0 1 TENSIONER, ROSTA
12 8.921-205.0 1 LABEL, MOTOR ROTATION
13 9.802-767.0 2 SCREW, 3/8" X 3/4" NC WHIZ LOC FLANGE
14 9.802-778.0 3 NUT, 5/16", WHIZ LOC FLANGE
15 8.749-973.0 1 BUSHING, IDLER TENSIONER
16 8.718-625.0 3 BOLT, 5/16"- 18 X 3/4" CRRG
