71Landa ENG Dealer’s Manual 9.801-510.0 - AV
Electrical Box - NG 4-5
NG 4-2000, 4-2200, 4-3000, 5-2300, 5-3000
REF PART NO. QTY DESCRIPTION NOTES
26 8.713-080.0 2 FUSE, CLASS R 1 AMP (208/230 1PH & 3PH)
- 8.713-081.0 2 FUSE, CLASS R 1/2 AMP (460/575 3PH)
27 8.718-730.0 2 SCREW, 10/32" X 2-1/2" RND HD MCH
28 8.900-207.0 1 LABEL, INCOMING POWER
29 8.716-460.0 1 TERMINAL, GROUND LUG, LAMA6-14-Q
30 8.753-544.0 1 TERMINAL, BLOCK, 3-POLE 85 AMP
31 9.800-040.0 2 LABEL, GROUND SYMBOL
32 9.802-762.0 1 SCREW, 10/32" X 1-1/4" RH, SL, BLK
33 8.916-343.0 1 LABEL, PE/HE TESTED
34 9.802-764.0 4 SCREW, 10/32" X 3/4", HEX WASH SL MACH/BLK
35 9.802-785.0 2 NUT, 8/32", KEPS
36 9.801-608.0 1 LABEL, FUSE KTK -.50 (460V, 575V)
- 9.801-626.0 1 LABEL, FUSE KTK-1 (208V, 230V)
37 9.801-607.0 1 LABEL, FUSE FMN-4
38 9.802-525.0 2 LOCKNUT, 1/2"
