79Landa ENG Dealer’s Manual 9.801-510.0 - AV
Control Panel - NG 6-10
NG 6-3200, 8-3200, 10-3000
REF PART NO. QTY DESCRIPTION NOTES
1 9.802-188.0 1 VALVE, METERING, 1/4" HOSE
2 6.390-126.0 1 CLAMP, HOSE, .46-.54 ST
3 9.802-251.0 10ft TUBE, 1/4" X 1/2",CLEAR VINYL
4 8.707-058.0 1 STRAINER, 1/4" BRASS W/CHECK VALVE
5 9.802-252.0 32" HOSE, 1/4" X 1/2",BRAIDED VINYL
6 9.802-064.0 3 GROMMET, RUBBER,NOZZEL HOLDER
7 8.712-369.0 1 NOZZLE, SAQCMEG, 0007, RED (6-3200)
- 8.712-378.0 1 NOZZLE, SAQCMEG, 0009, RED (8-3200)
- 8.707-760.0 1 NOZZLE, #11 X 0° 1/4" MEG (10-3000)
8 8.712-370.0 1 NOZZLE, SAQCMEG, 1507, YELLOW (6-3200)
- 8.712-379.0 1 NOZZLE, SAQCMEG, 1509 YELLOW (8-3200)
- 8.707-763.0 1 NOZZLE, #11 X 40° 1/4" MEG (10-3000)
9 8.712-372.0 1 NOZZLE, SAQCMEG, 4007, WHITE (6-3200)
- 8.712-381.0 1 NOZZLE, SAQCMEG, 4009
- 8.707-761.0 1 NOZZLE, #11 X 15° 1/4" MEG (10-3000)
10 9.807-574.0 1 LABEL, CONTROL VALVES NG
11 8.750-095.0 1 THERMOSTAT, 120C/240F,2 METER CAPILLARY
12 9.802-283.0 1 HOUR METER, 24-240VAC 50/60HZ
13 8.921-640.0 1 CONTROL PANEL, NG/LM
14 9.801-585.0 1 LABEL, CONTROL PANEL, NG-L
15 8.753-257.0 3 LIGHT, INDICATOR, CLEAR 28V
16 8.712-190.0 1 BEZEL, PLASTIC, THERMOSTAT (915390)
17 8.718-779.0 2 SCREW, 4MM X 6MM PAN HEAD
18 8.716-037.0 2 SWITCH, ROCKER, 10A/250V-15A/125V, 24VLT
19 8.726-103.0 2 SCREW, 1/4"-20 X 5/8",WHIZ LOC BLK CAD
20 8.753-255.0 2 NUT, EXTRUDED U-NUT, 1/4"-20
21 8.750-097.0 1 KNOB, THERMOSTAT 120C/248F
22 9.802-171.0 3 COUPLER, 3/8" PLUG, MALE STEEL/ZINC (10-3000)
