83Landa ENG Dealer’s Manual 9.801-510.0 - AV
Panels & Doors - NG 6-10
NG 6-3200, 8-3200, 10-3000
REF PART NO. QTY DESCRIPTION NOTES
1 8.921-647.0 1 PANEL, TOP, NG/LM
2 8.753-255.0 8 NUT, EXTRUDED U-NUT, 14"-20
3 8.726-103.0 8 SCREW, 1/4"-20 X 5/8" WHIZ LOC BLK CAD
4 8.753-494.0 1 START COLLAR, 12"
5 9.800-006.0 1 LABEL, HOT CALENTE W/ARROWS
6 9.800-013.0 1
LABEL, ASSEMBLED IN USA
INTENDED FOR INDOOR USE
7 9.800-034.0 1 LABEL, CLEAR LEXAN, 4.3" X 5.5"
8 8.932-965.0 1 LABEL, WARNING - EXPOSED PULLEYS
9 8.900-990.0 1 LABEL, INSTRUCTIONS/WARNINGS
10 9.800-016.0 1 LABEL, DISCONNECT POWER SUPPLY
11 8.900-802.0 1 LABEL, LANDA LOGO 25.75 X 6.0"
12 8.900-207.0 1 LABEL, INCOMING POWER
13 8.932-964.0 1 LABEL, NATURAL GAS ONLY
14 9.800-020.0 1 LABEL, COLD WATER INLET
15 9.800-021.0 1 LABEL, HOT WATER OUTLET
16 9.800-049.0 1 LABEL, MANUFACTUERS CLEANING SOLUTION
17 8.921-645.0 1 DOOR, SIDE, CONTROL, NG/LM
18 8.921-635.0 2 DOOR, END PANEL, NG/LM
19 8.921-644.0 2 DOOR, SIDE, COIL, NG/LM
20 8.753-254.0 12 BALL STUD, LARGE, 5/16" ZINC
21 9.802-778.0 12 NUT, 5/16" WHIZ LOC FLANGE
22 9.802-068.0 12 PLUG, RUBBER, SJ-10/15 P/N 1372-26012
23 8.719-081.0 6 LATCH, SPRING FLUSH HEAD
24 8.753-462-0 12 RIVET, 1/8" BLACK STEEL
25 8.921-646.0 1 DOOR, SIDE, PUMP, NG/LM
