95Landa ENG Dealer’s Manual 9.801-510.0 - AV
Pump M.3 Series
REF PART NO. QTY DESCRIPTION NOTES
25 9.803-192.0 2 O-RING Ø1.78 X 60.05
26 8.933-011.0 2 TAPERED ROLLER BEARING
27 8.751-222.0 1 CRANKSHAFT (5030,3540)
- 8.751-223.0 1 CRANKSHAFT (4030, 4035, 6035)
28 9.803-167.0 1 CRANKSHAFT KEY
29 9.802-921.0 1 OIL DIP STICK
30 9.803-140.0 1 CRANKSHAFT SEAL
31 9.803-178.0 2 SHIM
32 8.717-209.0 1 BEARING HOUSING
33 - 3 PLUNGER NUT, M* SEE KITS TABLE
34 - 3 COPPER SPACER SEE KITS TABLE
35 - 3 PLUNGER (4035, 6035) SEE KITS TABLE
35 - 3 PLUNGER (4030, 5030) SEE KITS TABLE
- - 3 PLUNGER (3540) SEE KITS TABLE
36 - 3 COPPER SPACER SEE KITS TABLE
37 - 3 O-RING Ø1.78 X 7.66 SEE KITS TABLE
38 - 3 TEFLON RING SEE KITS TABLE
39 8.751-224.0 3 PLUNGER ROD
40 9.803-158.0 3 CONNECTING ROD
41 8.751-228.0 3 CONNECTING ROD PIN
42 9.803-218.0 6 SPRING WASHER
43 9.803-238.0 6 CONNECTING ROD SCREW
44 8.933-016.0 1 O-RING, Ø2.62 X 126.67
45 8.751-229.0 1 CRANKCASE COVER
46 9.803-197.0 1 O-RING, Ø1.78 X 14
47 9.803-202.0 1 SIGHT GLASS 3/4
48 9.802-939.0 5 COVER SCREW
KIT NUMBERS 8.725-360.0 8.725-362.0 8.725-358.0 8.725-361.0 9.725-363.0 8.725-359.0
KIT DESCRIPTION
Plunger Seals
LM-4035
LM-6035
18 mm
Plunger Seals
LM-4030
LM-5030
20 mm
Plunger
LM-3540
15 mm
Complete Seal
Packing
LM-4035
LM-6035
18 mm
Complete Seal
Packing
LM-4030
LM-5030
20 mm
Complete
Seal Packing
LM-3540
15 mm
ITEM NUMBERS INCLUDED 3, 5, 7 3, 5, 7 3, 5, 7 3, 4, 5, 6, 7 3, 4, 5, 6, 7 3, 4, 5, 6, 7
NUMBER OF CYLINDERS
KIT WILL SERVICE
3331 11
KIT NUMBERS 8.751-237.0 8.751-238.0 8.933-023.0 8.802-603.0 9.802-609.0
KIT DESCRIPTION
Plunger Seals
LM-4035
LM-6035
18 mm
Plunger
LM-4030
LM-5030
20 mm
Plunger
LM-3540
15 mm
Complete
Valve
Plunger Oil
Seals
ITEM NUMBERS INCLUDED 33, 34, 35, 36, 37, 38 33, 34, 35, 36, 37, 38 33, 34, 35, 36, 37, 38 11, 12, 13 2
NUMBER OF CYLINDERS
KIT WILL SERVICE
31163
