27Landa PGDC Operator’s Manual 8.916-596.0 - P
Landa PGDC
REF PART NO. QTY DESCRIPTION NOTES
1 8.706-604.0 1 TANK, FUEL, 5 GAL., RED 1.110-050.0, 1.110-051.0
2 8.706-603.0 1 TANK, FUEL, 10 GAL. POLY YELLOW
3 8.921-148.0 2 STRAP, FUEL TANK SINGLE 1.110-049.0
- - 1 STRAP, FUEL TANK SINGLE - 1.110-050.0, 1.110-051.0
4 9.802-193.0 2 GASKET, NEOPRENE 7" 1.110-049.0
- - 3 GASKET, NEOPRENE 7" 1.110-050.0, 1.110-051.0
5 9.802-053.0 2 BUSHING, RUBBER, NITRILE 1.110-049.0
- - 3 BUSHING, RUBBER, NITRILE 1.110-050.0, 1.110-051.0
6 9.802-054.0 1 ELBOW, FUEL TANK, ZINC
7 8.706-496.0 1 DIPTUBE ASSY, PLASTIC, 17.5" 1.110-049.0
- - 2 DIPTUBE ASSY, PLASTIC, 17.5" 1.110-050.0, 1.110-051.0
8 8.912-192.0 1 TOP WRAP, STAINLESS STEEL
9 9.802-071.0 33" TRIM, 750 B2 X 1/16 BLACK
10 9.800-002.0 1 LABEL, USE ONLY KEROSENE
11 9.800-006.0 1 LABEL, WARNING, HOT/CALIENTE W/ARROWS
12 6.390-126.0 3 HOSE CLAMP 1.110-049.0
- - 5 HOSE CLAMP 1.110-050.0, 1.110-051.0
13 8.706-727.0 1 BUSHING, 5/16", SNAP LOK
14 8.918-426.0 1 HOSE, 3/8" X 32", 2 WIRE PRESSURE LO
1.110-049.0, 1.110-050.0,
1.110-051.0
- 8.918-227.0 1 HOSE, 1/2" X 36", 2 WIRE, PRESSURE LO 1.110-072.0
15 8.918-425.0 1 HOSE, 3/8" X 29", 2 WIRE, PRESSURE LO
1.110-049.0, 1.110-050.0,
1.110-051.0
- 8.918-225.0 1 HOSE, 1/2" X 28", 2 WIRE, PRESSURE LO 1.110-072.0
16 9.802-781.0 6 NUT, 3/8" WHIZ
17 8.718-980.0 23 WASHER, 5/16" FLAT, SAE
18 9.802-776.0 23 NUT, 5/16" ESNA, NC
19 9.802-261.0 39" HOSE, 3/4"
20 9.802-728.0 2 THREADED BOLT 3/8" X 2"
21 9.802-779.0 2 NUT, 3/8"
22 9.802-807.0 2 WASHER, FLAT, 3/8"
23 9.802-259.0 24" HOSE, 1/2" PUSH-ON
24 9.802-151.0 2 SWIVEL, 1/2" JIC FEM PUSH-ON
25 8.707-020.0 1 1/2" MPT X 3/4" BARB
26 8.900-839.0 1 LABEL, PGDC SKID WARNING
27 9.802-152.0 1 SWIVEL, 3/4" SAE FEM, PUSH-ON
28 9.802-767.0 13 SCREW, 3/8" X 3/4" HH, NC, WHIZ
29 8.718-674.0 2 BOLT, 3/8-16 X 2-1/4", GR8.2 SERATED FLANGE B
30 8.752-918.0 1 CLAMP, HOSE #64SS
31 9.802-781.0 2 NUT, 3/8" FLANGE WHIZ LOC NC
32 8.706-600.0 1 BATTERY, M-100, LARGE
33 8.916-471.0 1 ASSY, POWER PLATFORM PGDC5-3500
34 8.932-992.0 9 MOUNT, RUBBER VIBRATION. 3/8" 70 DURO
