Landa Pgdc5-3500 - Unloader - 4-3500, 5-3500

40
Unloader - 4-3500, 5-3500
REF PART NO. QTY DESCRIPTION NOTES
1 9.802-039.0 1 ELBOW, 1/2" JIC X 3/8" MPT
2 9.802-870.0 1 BLOCK, UNLOADER, 3/8 X 3/8, 1.25 BRASS
3 9.802-048.0 1 SWIVEL, 1/2" JIC FEM, 3/8" MAL
4 9.802-036.0 2 NIPPLE, 1/2 JIC, 3/8 PIPE
5 9.802-129.0 1 ELBOW, 1/2" JIC X 3/8" 90°
6 8.750-299.0 1 UNLOADER VRT 3, 8 GPM @ 4500 PSI
7 8.933-006.0 1 SWITCH, FLOW MV60
8 8.705-974.0 1 NIPPLE, 3/8" HEX STEEL
9 8.706-965.0 1 HOSE BARB, 1/4" X 3/8" 90°
10 9.802-254.0 6 ft. HOSE, 1/4 PUSH-ON
Landa PGDC Operator’s Manual 8.916-596.0 - P
1
2
3
7
10
5
6
8
4
4
9
Float Tank
Option Only
