31Landa PGDC Operator’s Manual 8.916-596.0 - P
Power Platform
REF PART NO. QTY DESCRIPTION NOTES
1--ENGINE
SEE SPECIFICATIONS
PAGE
2 9.802-695.0 1 NUT, 10/32" KEPS 1.110-049.0
3--PUMP
SEE SPECIFICATIONS
PAGE
4 8.916-442.0 1 WLMT, PLATFORM PGDC
5 9.802-764.0 - SCREW, 10/32 X 3/4 HEX, WASH SL MACH/BLK 1.110-049.0
6 - - PUMP PULLEY
SEE SPECIFICATIONS
PAGE
7 - - ENGINE PULLEY
SEE SPECIFICATIONS
PAGE
8 8.709-089.0 1 CLIP, .25ID RND 1.110-049.0
9 - - PUMP BUSHING
SEE SPECIFICATIONS
PAGE
10 - - ENGINE BUSHING
SEE SPECIFICATIONS
PAGE
11 9.802-125.0 1 PLUG, 1/4" JIC 1.110-049.0
12 9.802-153.0 1 SWIVEL, 1/4" JIC FEM, PUSH-ON 1.110-049.0
13 9.803-845.0 1 BOLT, 1/2" X 5" NC HH TAP ALL THREAD
14 9.802-800.0 1 WASHER, 1/2" FLAT
15 9.802-767.0 11 SCREW, 3/8" X 3/4" HH, NC WHIZ
16 9.802-154.0 1 PLUG, PUSH-ON, OIL DRAIN, HONDA 1.110-049.0
17 9.802-779.0 2 NUT, 3/8"
18 9.802-807.0 8 WASHER, FLAT 3/8"
19 9.802-959.0 1 KEY, 0.247 SQR X 2.125"
20 8.912-457.0 1 WLMT, BELT GUARD, GAS PUMP 1.110-050.0, 1.110-051.0
- 8.922-994.0 1 WLMT, BELT GUARD, 13 HP, 1.110-049.0
21 9.802-254.0 7" HOSE, 1/4" 1.110-049.0
22 8.916-610.0 1 GUARD, BELT, LEFT
23 9.800-006.0 2 LABEL, WARNING, HOT/CALIENTE W/ARROWS
24 8.932-965.0 2 LABEL, WARNING, EXPOSED PULLEYS
25 9.802-775.0 3 NUT, 1/4" FLANGE, ZN 1.110-050.0
26 8.913-902.0 1 KEY, RING LANDA
27 9.802-445.0 8" WRAP, SPIRAL
28 8.716-491.0 1 CABLE, BATTERY, 61" EYE TO POST, RED
29 8.716-492.0 1 CABLE, BATTERY, 61" EYE TO POST BLACK
30 9.802-761.0 4 SCREW, M6 X 20MM BH SOC BLACK 1.110-051.0
31 9.802-259.0 7 HOSE, 1/2" PUSH-ON
32 9.802-151.0 1 SWIVEL, 1/2" JIC FEM, PUSH-ON
33 9.802-126.0 1 PLUG, 1/2" JIC FLARE 639F-8"
34 9.802-728.0 2 THREADED BOLT 3/8" X 2"
35 9.802-771.0 2 SCREW, 10/32" X 3/4" BH SOC CS
36 9.802-695.0 2 NUT, 10/32" KEPS
37 8.750-737.0 1 ADAPTER, HONDA , M20-1.5 X 3/8"
